MED 3044

Double-Coated Film

MED 3044 is a double-coated, conformable, transparent polyethylene film with an acrylic adhesive on both sides. This product is designed to adhere to many foams, films and nonwovens, and has a heavy-weight liner, allowing for greater flexibility in product design and converting processes.

Typical Application

Designed for mounting medical devices to the skin for sustained periods of wear.

Features and Benefits
  • Conformable
  • Moisture resistant
  • Transparent
  • Die-cuttable
  • Gamma and EtO sterilizable
  Product Construction Typical Values*    Description
  Unwind Adhesive Thickness
 2.0 mils 50 μm
   Acrylic adhesive designed for medical applications
  Carrier Thickness
 3.0 mils 75 μm
   Transparent polyethylene film
  Liner Adhesive Thickness
 2.0 mils 50 μm
   Acrylic adhesive designed for medical applications
  Liner Thickness
 5.5 mils 140 μm
   White double-coated kraft



  Physical Properties (Not intended as a specification.) Test Method** Typical Values*
  Peel Adhesion on Polyethylene (PE) - Liner
 TDS-01
 0.7 lbf/in
 3.1 N/25 mm
  Peel Adhesion on Polyethylene (PE) - Unwind
 TDS-01 0.7 lbf/in
 3.1 N/25 mm
  Peel Adhesion on Stainless Steel (SS) - Liner
 TDS-03 3.1 lbf/in
 13.5 N/25 mm
  Peel Adhesion on Stainless Steel (SS) - Unwind
 TDS-03 4.2 lbf/in
 18.5 N/25 mm
  Liner Release
 TDS-06 2.3 oz/in
 65 g/25 mm
  Finat Tack - Liner
 TDS-07
 1.5 lbf/in
 7 N/25 mm
  Finat Tack - Unwind
 TDS-07
 3.8 lbf/in
 17 N/25 mm
  Dynamic Shear - Liner
 TDS-10
 23 lbf/in
 100 N/25 mm
  Dynamic Shear - Unwind
 TDS-10 23 lbf/in
 100 N/25 mm
  Elongation Machine Direction TDS-15 525%
  Elongation Cross Direction TDS-15 800%
  Load at Break Machine Direction TDS-15 10 lbf/in
 45 N/ 25mm
  Load at Break Cross Direction TDS-15 9 lbf/in
 40 N/ 25mm

*Refer to product specifications for material acceptance limits.
**Test method information available upon request.





STORAGE AND SHELF LIFE

Two years when stored at 23°C (73°F), 50% relative humidity, out of direct sunlight, in original packaging.
