Product Construction |
Typical Values |
Description |
Release Liner Thickness |
2.7 mils |
70 mm
|
White super-calendered glassine
|
Adhesive Thickness |
1.8 mils |
45 μm
|
Acrylic adhesive designed for medical applications |
Carrier Thickness
|
1.0 mils |
25 µm
|
Transparent co-polyester film
|
Physical Properties (Not intended as a specification.) |
Test Method* |
Typical Values✝ |
Peel Adhesion on Polyethylene (PE) |
TDS-01 |
0.7 lbf/in
|
3.0 N/25 mm |
Peel Adhesion on Stainless Steel (SS)
|
TDS-03 |
2.7 lbf/in
|
11.5 N/25 mm
|
Liner Release |
TDS-06
|
0.9 oz/in
|
25 g/25 mm
|
Finat Tack
|
TDS-07 |
5.6 lbf/in
|
24 N/25 mm
|
Dynamic Shear
|
TDS-10 |
47 lbf/in
|
210 N/25 mm
|
Elongation - Machine Direction |
TDS-15 |
725% |
Elongation - Cross Direction |
TDS-15 |
725% |
Load at Break - Machine Direction |
TDS-15 |
4 lbf/in
|
15 N/ 25mm
|
Load at Break - Cross Direction |
TDS-15 |
3 lbf/in
|
15 N/ 25mm
|
MVTR |
TDS-16 |
40 g/100 in2/24h |
600 g/m2/24h
|
✝Refer to product specifications for material acceptance limits.
STORAGE AND SHELF LIFE
Two years when stored at 23°C (73°F), 50% relative humidity, out of direct sunlight, in original packaging.
IMPORTANT
Information on the above characteristics is based upon tests we believe to be reliable. The values given are typical values that vary according to application conditions. The values are intended only as a source of information and are given without guarantee and do not constitute a warranty. This document is not a product specification. Purchasers should independently determine prior to use the suitability of this material for their specific purposes. All Avery Dennison materials described herein are sold subject to Avery Dennison Conditions of Sales, a copy of which is available upon request.
